Brand

Display Device

Display System	SXRD projection system
Size of effective display area	0.74" x 3 SXRD
Number of pixels	26,542,080 (4096 x 2160 x 3) pixels

Projection Lens

Focus	Powered
Zoom - Powered/Manual	Powered
Zoom - Ratio	Approx. x 2.06
Lens Shift	Powered

Light source

Type	Ultra high pressure mercury lamp
Wattage	330 W type
Screen size	60" to 300" (1.52 m to 7.62 m) (measured diagonally)

Light output

Lamp mode: High

2000 lm

Contrast

Contrast ratio (full white / full black)

1,000,000:1 (Dynamic Contrast)

Display resolution

Computer signal input	Maximum display resolution: 1920 x 1080 dots (HDMI Input only)
Video signal input	480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p, 1080/24p, 3840×2160/24p, 3840×2160/25p, 3840×2160/30p, 3840×2160/50p, 3840×2160/60p, 4096×2160/24p, 4096×2160/25p, 4096×2160/30p, 4096×2160/50p, 4096×2160/60p

Keystone Correction

Vertical	48 Hz to 92 Hz
Horizontal	19 kHz to 72 kHz

INPUT OUTPUT (Computer/Video/Control)

INPUT B	RGB/Y Pb/Cb Pr/Cr input connector: Mini D-sub 15-pin (female)
IO REMOTE	RS-232C connector: D-sub 9-pin (female)
IO LAN	RJ-45, 10Base-T/100BASE-TX
HDMI 1 / HDMI 2	HDMI (x2)
Y PB/CB PR/CR	Pin Jack (x3)
IR IN	Mini Jack
Trigger	Mini Jack (x2)
3D SYNC	RJ-45

Acoustic Noise

Lamp mode: Low

23 dB

Dimension and Mass

Dimensions (W x H x D) (without protrusions)	520 x 200 x 640 mm (20 1/2 x 7 7/8 x 25 1/4 inches)
Mass	20 kg (44 lb)

Others

Projector Power requirements	AC 100 V to 240 V, 4.8 A to 2.0 A, 50 Hz / 60 Hz
Remote commander	RM-PJ22
Optional Lamp	LMP-H330
IR 3D Glasses	TDG-PJ1
IR External Transmitter	TMR-PJ2
Wireless HD Unit	IFU-WH1
