Brand

Display Device

Display System	3 LCD system
Size of effective display area	0.59” (15 mm) x 3 BrightEra LCD Panel, Aspect ratio: 16:10
Number of pixels	3,072,000 (1280x800 x 3) pixels

Projection Lens

Focus	Manual
Zoom - Powered/Manual	Manual
Zoom - Ratio	Approx. x 1.3
Throw Ratio	1.36:1 to 1.77:1

Light source

Type	Ultra high pressure mercury lamp
Wattage	210 W type
Screen size	30" to 300" (0.76 m to 7.62 m)(measured diagonally)

Light output

Lamp mode: High	2600lm
Lamp mode: Standard	1900lm
Lamp mode: Low	1500lm

Contrast

Contrast ratio (full white / full black)

3000:01:00

Speaker

Speaker

1 W x 1 (monaural)

Display resolution

Computer signal input	Maximum display resolution: UXGA 1600 x 1200 dots*3
Video signal input	NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/60p, 1080/50p

Keystone Correction

Vertical

+/- 30°

INPUT OUTPUT (Computer/Video/Control)

INPUT A	RGB / Y PB PR input connector: Mini D-sub 15 pin female Audio input connector: Stereo mini jack (shared with VIDEO IN)
INPUT B	HDMI input connector: HDMI 19-pin, HDCP support
VIDEO IN	Video input connector: Pin jack Audio input connector: Shared with INPUT A
IO LAN	RJ-45, 10BASE-T/100BASE-TX
IO USB	Type-A Type-B

Acoustic Noise

Lamp mode: Low

< 35 dB

Dimension and Mass

Dimensions (W x H x D) (without protrusions)	Approx. 315 x 75 x 230.5 mm (12 13/32 x 2 15/16 x 9 1/16 inches)
Mass	2.6 kg (5.8 lb)

Others

Projector Power requirements	AC 100 V to 240 V, 3.0 A to 1.2 A, 50 Hz / 60 Hz
Remote commander	RM-PJ8
Optional Lamp	LMP-D213
Wireless LAN module	IFU-WLM3
