Brand

Display Device

Display System	4K SXRD projection system
Size of effective display area	1.48" x 3 SXRD
Number of pixels	26,542,080 (4096 x 2160 x 3) pixels

Light source

Type	High-pressure mercury lamp
Wattage	450 W (4) or 330 W (4) type

Light output

Lamp mode: High

9000 lm

Contrast

Contrast ratio (full white / full black)

8000:1

INPUT OUTPUT (Computer/Video/Control)

VIDEO IN	HDMI (1) *2
IO Output	Unbalance, 8 channels, 24 bit, 48/96 kHz, linear PCM, D-sub 25-pin (female) (1) AES/EBU, 16 channels, 24 bit, 48/96 kHz, linear PCM, D-sub 25-pin (female) (1)

Dimension and Mass

Dimensions (W x H x D) (without protrusions)	W548 x H634 x D1119 mm
Mass	Approx. 145 kg (Excluding touch panel monitor, lamp and lens)

Others

Projector Power requirements	AC 200 V to 240 V, 21.5 A to 18 A, 50/60 Hz, Single Phase
Optional Lamp	LKRM-U450/LKRM-U330
