Brand

Dimension and Mass

Dimensions	W510 x H185 x D470 mm
Weight	39.8kg

Input/Output/Control

Input	Mono 6 x Mic 0.6mV/4.7k ohm, 2 x Aux 100mV/470k ohm, Stereo L/R 200mV/100k ohm, Line L/R 1V/50k ohm
Output	Preamp 200mV/600 ohm, Line 1V/1k ohm
Speaker Output	4 ohm, 8 ohm, 70V& 100V for each zone

Technical Features

Power Requirement	AC: 220-240V 50/60Hz ohm DC: 24V (2x—12V Car Battery)
S/N Ratio	60dB
Frequency Response	50-15,000Hz ±3dB
Controls	Tone Controls Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHz
